Device_gate.cpp File Reference

#include "Device_gate.h"
#include <iostream>
#include <sstream>

Include dependency graph for Device_gate.cpp:

Functions
DeviceGateResult	evaluateDeviceGate (Element &elem, const std::string &device_id, const CertificateSpec &spec)
	Evaluate passivity / phase / geometric certificates on device Y(jω).
void	reportDeviceGate (const DeviceGateResult &result, bool plotting_enabled)
	Register gate plots and print a one-line verdict.

Function Documentation

evaluateDeviceGate()

DeviceGateResult evaluateDeviceGate	(	Element &	elem,
		const std::string &	device_id,
		const CertificateSpec &	spec
	)

Evaluate passivity / phase / geometric certificates on device Y(jω).

ALLOW only if all enabled checks in spec pass. Intended as a local plug-and-play gate before interconnecting into an unknown network.

References DeviceGateResult::allow, DeviceGateResult::device_id, CertificateSpec::label, DeviceGateResult::pass_dw, CertificateSweep::pass_dw, DeviceGateResult::pass_nr_phase, CertificateSweep::pass_nr_phase, DeviceGateResult::pass_nr_zero, CertificateSweep::pass_nr_zero, DeviceGateResult::pass_passivity, CertificateSweep::pass_passivity, DeviceGateResult::pass_phase, CertificateSweep::pass_phase, DeviceGateResult::pass_sector, CertificateSweep::pass_sector, DeviceGateResult::pass_shifted, CertificateSweep::pass_shifted, DeviceGateResult::pass_small_gain, CertificateSweep::pass_small_gain, DeviceGateResult::reason, CertificateSpec::require_dw, CertificateSpec::require_nr_phase, CertificateSpec::require_nr_zero_outside, CertificateSpec::require_passivity, CertificateSpec::require_phase, CertificateSpec::require_sector, CertificateSpec::require_shifted, CertificateSpec::require_small_gain, DeviceGateResult::sweep, sweepDeviceCertificate(), sweepPassesSpec(), CertificateSweep::worst_nr_phase_deg, CertificateSweep::worst_nr_zero_margin, CertificateSweep::worst_passivity, CertificateSweep::worst_phase_deg, CertificateSweep::worst_shifted, and CertificateSweep::worst_small_gain.

Referenced by example_certificate_figures().

reportDeviceGate()

void reportDeviceGate	(	const DeviceGateResult &	result,
		bool	plotting_enabled
	)

Register gate plots and print a one-line verdict.

References DeviceGateResult::device_id, plot_certificate_gate(), plot_certificate_geometric_sweep(), plot_certificate_passivity(), plot_certificate_phase(), DeviceGateResult::reason, and DeviceGateResult::sweep.

Referenced by example_certificate_figures().
