Implementation of Standard numeric constants and matrix utility functions. More...

#include "Standard_functions.h"

Include dependency graph for Standard_functions.cpp:

Functions
int	sgn (int v)
	Computes the sign of an integer.

MatrixXcd	vectorToMatrix (const vector< vector< complex< double > > > &vec)
	Converts a 2D vector of complex numbers to an Eigen matrix.

MatrixXd	vectorToMatrix (const vector< vector< double > > &vec)
	Converts a 2D vector of complex numbers to an Eigen matrix.

vector< vector< complex< double > > >	matrixToVector (const MatrixXcd &mat)
	Converts an Eigen matrix of complex numbers to a 2D vector.

vector< vector< double > >	matrixToVector (const MatrixXd &mat)
	Converts an Eigen MatrixXd to a nested real vector.

MatrixXcd	stack_u_4x_3xN (const MatrixXcd &u1, const MatrixXcd &u2, const MatrixXcd &u3, const MatrixXcd &u4)
	Stacks four input matrices into a single block column.

vector< vector< complex< double > > >	mat_mul (const vector< vector< complex< double > > > &A, const vector< vector< complex< double > > > &B)
	Multiplies two matrices represented as 2D vectors.

vector< vector< complex< double > > >	mul_scalar (const vector< vector< complex< double > > > &A, const complex< double > &scalar)
	Multiplies a matrix by a scalar value.

vector< vector< complex< double > > >	mat_add (const vector< vector< complex< double > > > &A, const vector< vector< complex< double > > > &B)
	Adds two matrices of the same dimensions.

vector< vector< complex< double > > >	mat_sub (const vector< vector< complex< double > > > &A, const vector< vector< complex< double > > > &B)
	Subtracts one matrix from another.

vector< vector< complex< double > > >	mat_transpose (const vector< vector< complex< double > > > &A)
	Transposes a matrix.

vector< vector< complex< double > > >	get_block (const vector< vector< complex< double > > > &Y, int r_off, int c_off, int r_num, int c_num)
	Extracts a block (submatrix) from a given matrix.

Variables
const double	mu_0 = 4 * M_PI * 1e-7
	Magnetic constant (permeability of free space).

const double	epsilon_0 = 8.854e-12
	Electric constant (permittivity of free space).

const double	gamma_num = 0.5772156649
	Euler-Mascheroni constant.

Detailed Description

Implementation of Standard numeric constants and matrix utility functions.

Function Documentation

◆ get_block()

vector< vector< complex< double > > > get_block	(	const vector< vector< complex< double > > > &	Y,
		int	r_off,
		int	c_off,
		int	r_num,
		int	c_num
	)

extern

Extracts a block (submatrix) from a given matrix.

Extracts a rectangular sub-block from a complex matrix.

Parameters

Y	The source matrix.
r_off	The starting row index of the block.
c_off	The starting column index of the block.
r_num	The number of rows in the block.
c_num	The number of columns in the block.

Returns: A new matrix containing the specified block.

References j.

Referenced by Element::apply_transformation().

◆ mat_add()

vector< vector< complex< double > > > mat_add	(	const vector< vector< complex< double > > > &	A,
		const vector< vector< complex< double > > > &	B
	)

Adds two matrices of the same dimensions.

Element-wise addition of two complex matrices.

Parameters

A	The first matrix.
B	The second matrix.

Returns: The resulting matrix C = A + B.

References j.

Referenced by Element::apply_transformation().

◆ mat_mul()

vector< vector< complex< double > > > mat_mul	(	const vector< vector< complex< double > > > &	A,
		const vector< vector< complex< double > > > &	B
	)

Multiplies two matrices represented as 2D vectors.

Complex matrix multiplication using nested vectors.

Parameters

A	The left-hand side matrix.
B	The right-hand side matrix.

Returns: The resulting matrix C = A * B.

Exceptions

std::runtime_error if matrix dimensions are incompatible for multiplication.

References j.

Referenced by Element::apply_transformation().

◆ mat_sub()

vector< vector< complex< double > > > mat_sub	(	const vector< vector< complex< double > > > &	A,
		const vector< vector< complex< double > > > &	B
	)

Subtracts one matrix from another.

Element-wise subtraction of two complex matrices.

Parameters

A	The matrix from which to subtract.
B	The matrix to subtract.

Returns: The resulting matrix C = A - B.

References j.

◆ mat_transpose()

vector< vector< complex< double > > > mat_transpose ( const vector< vector< complex< double > > > & A )

Transposes a matrix.

Transposes a complex matrix stored as nested vectors.

Parameters

A	The matrix to transpose.

Returns: The transposed matrix.

References j.

Referenced by Element::apply_transformation().

◆ matrixToVector() [1/2]

vector< vector< complex< double > > > matrixToVector ( const MatrixXcd & mat )

Converts an Eigen matrix of complex numbers to a 2D vector.

Converts an Eigen MatrixXcd to a nested complex vector.

Parameters

mat	The input Eigen::MatrixXcd.

Returns: A 2D vector representation of the input matrix.

References j.

Referenced by Converter::plotParticipationFactors().

◆ matrixToVector() [2/2]

vector< vector< double > > matrixToVector ( const MatrixXd & mat )

Converts an Eigen MatrixXd to a nested real vector.

Parameters

mat	Input real matrix.

Returns: 2-D vector representation.

References j.

◆ mul_scalar()

vector< vector< complex< double > > > mul_scalar	(	const vector< vector< complex< double > > > &	A,
		const complex< double > &	scalar
	)

Multiplies a matrix by a scalar value.

Scales every entry of a complex matrix by a scalar.

Parameters

A	The matrix to be multiplied.
scalar	The complex scalar value.

Returns: The resulting matrix C = A * scalar.

References j.

Referenced by Element::apply_transformation().

◆ sgn()

int sgn ( int v )

Computes the sign of an integer.

Returns the sign of an integer.

Parameters

v	The integer value.

Returns: 1 if v > 0, -1 if v < 0, and 0 if v == 0.

Referenced by dq_multiply().

◆ stack_u_4x_3xN()

MatrixXcd stack_u_4x_3xN	(	const MatrixXcd &	u1,
		const MatrixXcd &	u2,
		const MatrixXcd &	u3,
		const MatrixXcd &	u4
	)

Stacks four input matrices into a single block column.

Parameters

u1	First input block.
u2	Second input block.
u3	Third input block.
u4	Fourth input block.

Returns: Vertically stacked complex matrix.

◆ vectorToMatrix() [1/2]

MatrixXcd vectorToMatrix ( const vector< vector< complex< double > > > & vec )

Converts a 2D vector of complex numbers to an Eigen matrix.

Converts a nested complex vector to an Eigen MatrixXcd.

Parameters

vec	The input 2D vector (matrix).

Returns: An Eigen::MatrixXcd representation of the input vector.

Exceptions

std::runtime_error if the inner vectors have inconsistent lengths.

References j.

Referenced by StabilityEstimate::compute_transfer_function(), example_MMC(), and example_stability_check().

◆ vectorToMatrix() [2/2]

MatrixXd vectorToMatrix ( const vector< vector< double > > & vec )

Converts a 2D vector of complex numbers to an Eigen matrix.

Converts a nested real vector to an Eigen MatrixXd.

Parameters

vec	The input 2D vector (matrix).

Returns: An Eigen::MatrixXcd representation of the input vector.

Exceptions

std::runtime_error if the inner vectors have inconsistent lengths.

References j.

Variable Documentation

◆ epsilon_0

const double epsilon_0 = 8.854e-12

Electric constant (permittivity of free space).

Vacuum permittivity (F/m).

Referenced by Cable::Cable(), and Overhead_Line::Overhead_Line().

◆ gamma_num

const double gamma_num = 0.5772156649

Euler-Mascheroni constant.

Euler–Mascheroni constant.

Referenced by Cable::Cable().

◆ mu_0

const double mu_0 = 4 * M_PI * 1e-7

Magnetic constant (permeability of free space).

Vacuum permeability (H/m).

Referenced by Cable::Cable(), and Overhead_Line::Overhead_Line().
