Implementation of Interactive ImGui/ImPlot visualization for solver results. More...

#include "Constants.h"
#include "Visualization.h"
#include "ui/harmony_banner_gui.h"
#include "stb_image_write.h"

Include dependency graph for Visualization.cpp:

Macros
#define	STB_IMAGE_WRITE_IMPLEMENTATION

Functions
static void	glfw_error_callback (int error, const char *desc)

static void	init_gui ()

static void	draw_plot_tabs (const char *tabBarId)

static void	gui_loop ()

static void	ensure_running ()

static void	add_tab (const std::string &title, std::function< void()> fn)

void	visualization_set_embedded_mode (const bool enabled)
	Use the host ImGui/GLFW context (HarmonyUI) instead of a background window.

void	visualization_stop ()
	Closes the visualization window and stops the GUI thread.

bool	visualization_is_running ()
	Returns whether the visualization window is currently open.

bool	visualization_has_tabs ()
	Returns whether plot tabs are registered.

void	visualization_clear_tabs ()
	Remove all registered plot tabs (e.g.

void	visualization_draw_embedded (const char *tabBarId)
	Draw plot tabs inside the current ImGui window (embedded / HarmonyUI mode).

void	visualization_process_pending_save (GLFWwindow *window)
	Capture a pending PNG save after ImGui::Render() on `window`.

void	visualization_wait ()
	Block until the window is closed by the user.

void	visualization_save_tab (const std::string &tab_title, const std::filesystem::path &output_dir)
	Schedule a PNG capture of the named tab on the next rendered frame.

std::vector< std::string >	visualization_tab_titles ()
	Titles of tabs currently registered in the visualization window.

void	add_plot_tab (const std::string &title, std::function< void()> fn)
	Public interface used by external modules (e.g. viz_opf).

void	bode_plot_implot (const std::vector< double > &freq, const std::vector< std::vector< double > > &mag_dB, const std::vector< std::vector< double > > &phase_deg, const std::vector< std::string > &labels, const std::string &title)
	Opens a Bode magnitude/phase plot in the visualization window.

void	nyquist_plot_implot (const std::vector< std::vector< std::complex< double > > > &H_data, const std::vector< std::string > &labels, const std::string &title)
	Opens a Nyquist plot in the visualization window.

void	plot_eigenvalues_implot (const std::vector< std::complex< double > > &eigvals, const std::string &title)
	Plots eigenvalues in the complex plane.

void	plot_participation_factors_implot (const std::vector< std::vector< double > > &P, const std::vector< std::string > &state_labels, const std::vector< std::string > &mode_labels, const std::string &title)
	Plots participation factor heatmap (states vs modes).

void	plot_abc_waveforms_implot (const std::vector< double > &t, const Eigen::MatrixXd &Xabc, const std::string &title)
	Plots three-phase abc waveforms over time.

void	plot_abc_groups_implot (const std::vector< double > &t, const std::vector< Eigen::MatrixXd > &Xabc_groups, const std::string &title)
	Plots multiple abc waveform groups on shared axes.

void	viz_opf (const OPFVisualData &d)
	Registers an "AC/DC OPF" network diagram tab in the visualization window.

Detailed Description

Implementation of Interactive ImGui/ImPlot visualization for solver results.

Macro Definition Documentation

◆ STB_IMAGE_WRITE_IMPLEMENTATION

#define STB_IMAGE_WRITE_IMPLEMENTATION

Function Documentation

◆ add_plot_tab()

void add_plot_tab	(	const std::string &	title,
		std::function< void()>	fn
	)

Public interface used by external modules (e.g. viz_opf).

Registers a custom ImGui/ImPlot draw callback as a new tab.

References add_tab().

◆ add_tab()

static void add_tab	(	const std::string &	title,
		std::function< void()>	fn
	)

static

References ensure_running().

Referenced by add_plot_tab(), bode_plot_implot(), nyquist_plot_implot(), plot_abc_groups_implot(), plot_abc_waveforms_implot(), plot_eigenvalues_implot(), plot_participation_factors_implot(), and viz_opf().

◆ bode_plot_implot()

void bode_plot_implot	(	const std::vector< double > &	freq,
		const std::vector< std::vector< double > > &	mag_dB,
		const std::vector< std::vector< double > > &	phase_deg,
		const std::vector< std::string > &	labels,
		const std::string &	title
	)

Opens a Bode magnitude/phase plot in the visualization window.

Parameters

freq	Frequency axis (Hz).
mag_dB	Magnitude in dB, one vector per trace.
phase_deg	Phase in degrees, one vector per trace.
labels	Trace legend labels.
title	Plot window title.

References add_tab(), j, and kHarmonyPlotPanelHeightPx.

Referenced by StabilityEstimate::bodeplotTF(), and Element::plotYParameters().

◆ draw_plot_tabs()

static void draw_plot_tabs ( const char * tabBarId )

static

Referenced by gui_loop(), and visualization_draw_embedded().

◆ ensure_running()

static void ensure_running ( )

static

References gui_loop().

Referenced by add_tab().

◆ glfw_error_callback()

static void glfw_error_callback	(	int	error,
		const char *	desc
	)

static

Referenced by init_gui().

◆ gui_loop()

static void gui_loop ( )

static

References draw_plot_tabs(), and init_gui().

Referenced by ensure_running().

◆ init_gui()

static void init_gui ( )

static

References glfw_error_callback(), and harmonyConfigurePlotUi().

Referenced by gui_loop().

◆ nyquist_plot_implot()

void nyquist_plot_implot	(	const std::vector< std::vector< std::complex< double > > > &	H_data,
		const std::vector< std::string > &	labels,
		const std::string &	title
	)

Opens a Nyquist plot in the visualization window.

Parameters

H_data	Complex frequency response, one vector per trace.
labels	Trace legend labels.
title	Plot window title.

References add_tab(), and j.

Referenced by StabilityEstimate::nyquistplotTF().

◆ plot_abc_groups_implot()

void plot_abc_groups_implot	(	const std::vector< double > &	t,
		const std::vector< Eigen::MatrixXd > &	Xabc_groups,
		const std::string &	title
	)

Plots multiple abc waveform groups on shared axes.

Parameters

t	Time axis (s).
Xabc_groups	One 3�N matrix per signal group.
title	Plot window title.

References add_tab(), and kHarmonyPlotWaveformHeightPx.

Referenced by example_DQsym_DSSS2(), example_DQsym_RLC(), and DQsym::plot().

◆ plot_abc_waveforms_implot()

void plot_abc_waveforms_implot	(	const std::vector< double > &	t,
		const Eigen::MatrixXd &	Xabc,
		const std::string &	title
	)

Plots three-phase abc waveforms over time.

Parameters

t	Time axis (s).
Xabc	Waveform matrix (3 rows � N samples).
title	Plot window title.

References add_tab().

Referenced by example_DQsym_math_operations().

◆ plot_eigenvalues_implot()

void plot_eigenvalues_implot	(	const std::vector< std::complex< double > > &	eigvals,
		const std::string &	title
	)

Plots eigenvalues in the complex plane.

Parameters

eigvals	List of eigenvalues.
title	Plot window title.

References add_tab(), and kHarmonyPlotEigenHeightPx.

Referenced by Converter::plotEigenvalues().

◆ plot_participation_factors_implot()

void plot_participation_factors_implot	(	const std::vector< std::vector< double > > &	P,
		const std::vector< std::string > &	state_labels,
		const std::vector< std::string > &	mode_labels,
		const std::string &	title
	)

Plots participation factor heatmap (states vs modes).

Parameters

P	Participation factor matrix [state][mode].
state_labels	Row labels (state names).
mode_labels	Column labels (mode indices/names).
title	Plot window title.

References add_tab(), and j.

Referenced by Converter::plotParticipationFactors().

◆ visualization_clear_tabs()

void visualization_clear_tabs ( )

Remove all registered plot tabs (e.g.

before a new run).

◆ visualization_draw_embedded()

void visualization_draw_embedded ( const char * tabBarId )

Draw plot tabs inside the current ImGui window (embedded / HarmonyUI mode).

References draw_plot_tabs().

◆ visualization_has_tabs()

bool visualization_has_tabs ( )

Returns whether plot tabs are registered.

◆ visualization_is_running()

bool visualization_is_running ( )

Returns whether the visualization window is currently open.

Returns: True if the GUI is running.

Referenced by runJsonSimulation().

◆ visualization_process_pending_save()

void visualization_process_pending_save ( GLFWwindow * window )

Capture a pending PNG save after ImGui::Render() on window.

Referenced by runHarmonyLauncher().

◆ visualization_save_tab()

void visualization_save_tab	(	const std::string &	tab_title,
		const std::filesystem::path &	output_dir
	)

Schedule a PNG capture of the named tab on the next rendered frame.

Schedules a PNG capture of the named tab on the next rendered frame.

The file is written as "<tab_title>.png" in the working directory. Thread-safe: can be called from any thread.

◆ visualization_set_embedded_mode()

void visualization_set_embedded_mode ( bool enabled )

Use the host ImGui/GLFW context (HarmonyUI) instead of a background window.

Call before any simulation runs. Prevents a second GLFW/ImGui context that can crash with ImGui focus-scope errors.

Referenced by runHarmonyLauncher().

◆ visualization_stop()

void visualization_stop ( )

Closes the visualization window and stops the GUI thread.

Referenced by runHarmonyLauncher().

◆ visualization_tab_titles()

std::vector< std::string > visualization_tab_titles ( )

Titles of tabs currently registered in the visualization window.

◆ visualization_wait()

void visualization_wait ( )

Block until the window is closed by the user.

Blocks until the user closes the visualization window.

Referenced by runJsonSimulation().

◆ viz_opf()

void viz_opf ( const OPFVisualData & data )

Registers an "AC/DC OPF" network diagram tab in the visualization window.

Opens an interactive AC/DC OPF network diagram.

Returns immediately; the window stays open until the user closes it or visualization_stop() / visualization_wait() is called.

Parameters

data	OPF topology and solved bus/branch quantities.

References add_tab(), OPFVisualData::baseMVA_ac, OPFVisualData::baseMW_dc, OPFVisualData::branch_dc, OPFVisualData::branch_entire_ac, OPFVisualData::bus_dc, OPFVisualData::bus_entire_ac, OPFVisualData::conv_dc, OPFVisualData::gen_entire_ac, j, OPFVisualData::nbuses_ac, OPFVisualData::nconvs_dc, OPFVisualData::ngens_ac, OPFVisualData::ngrids, OPFVisualData::pgen_ac_k, OPFVisualData::pij_ac_k, OPFVisualData::pij_dc_k, OPFVisualData::pol_dc, OPFVisualData::ps_dc_k, OPFVisualData::qgen_ac_k, OPFVisualData::qij_ac_k, OPFVisualData::qs_dc_k, OPFVisualData::vn2_ac_k, and OPFVisualData::vn2_dc_k.

Referenced by PowerFlow::solve_opf().
